Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas

Negotiation
Price
Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas
Features Gallery Product Description Request A Quote
Features
Specifications
High Light:

aluminium Honeycomb sheet

,

decorative metal wall panels

Basic Infomation
Place of Origin: China Mainland
Brand Name: OUSILONG
Certification: ISO9001:2008, ISO14001:2004, CE, GB/T28001-2011, SGS Test, SONCAP
Model Number: N/A
Payment & Shipping Terms
Packaging Details: Export carton
Delivery Time: 15 working days
Payment Terms: T/T, L/C
Supply Ability: 4,000 PCS/week
Product Description

Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas

Aluminum Honeycomb Panel, decorative panel, shopping mall, exhibition hall


Product details

1. Product code: N/A
2. Color: Black / Stone, RAL color available
3. Dimension: 600 x 1200mm, Custom made available
4. Surface finishing: Fluorine carbon coated
5. Material: Aluminum alloy
6. Thickness: 12mm, 6~90mm available
7. Shape: Custom made available
8. Temperature tolerance: -60℃~ +120℃
9. Warranty: 15-20 years


Specification



 Type

 Material

 Thickness

 Surface
 Coating

 Size

 Color

 Aluminum  Honeycomb  Panel

 Aluminum    alloy

 Standard  thickness:
 10, 12,  15,
 18, 20,  25mm;  Custom
 made
 available

 Fluorine
 carbon
 coated

 Standard  width:1220,
 1250, 1500mm
 Length≤6000mm
 Width≤1500mm

 Black / Stone,  subject
 to user
 demand



Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas 0



Features

1. Aluminum Honeycomb Panel bases on grade 3003 aluminum alloy sheet, and the aluminum sheet owns water proof property. After PVDF coated on its surface, the whole panel has weather resistance, chemical preservation and etc;
2. When in installation, panels are tightly connected with sealed aluminum profiles from four sides, so as to prevent rainwater from osmosis;
3. Plug in installation method & weather silicone sealant are applied to achieve the best water proof effect;
4. Durable, washable, scrubbable, mortar resistant, corrosion resistance;
5. Custom made metal walls available to coordinate with ceilings and other interior / exterior finishings;
6. Unique system solutions or custom made designs;
7. Outstanding performance with high quality products;
8. Extensive in house production capabilities;
9. A wealth of industry experience;
10. Certificate: ISO9001:2008, ISO14001:2004, CE, SONCAP, GB/T28001-2011, SGS Test etc;


Accessaries

Aluminum Honeycomb Panel is with professional mold design, even panel surface, distinct edges & lines, and clear & concise. All of these create a pleasant visual space. It has multiple accessibility options.

Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas 1




Application





OUSILONG is one of the earliest metal ceiling enterprises who introduced ISO quality management system. We have first rate management & production teams, ensuring the survival root of an excellent enterprise

quality.



OUSILONG always takes technology innovation as its own mission and healthy living space creation as goal. We own around 100 senior technicians, and have signed a cooperation agreement of R & D in ceilings with a European enterprise to launch new crafts and develop new hi tech products constantly.

Industrial and civil buildings, special buildings, large span steel structure, building roof, exterior & interior wall decoration, facades of municipal buildings, exhibition halls, airports, stadiums, anti corrosion of steel structures, oil platform etc.

Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas 2

Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas 3


Installation

OUSILONGTM aluminum honeycomb panel is fully made from aluminum which is recyclable and environmental friendly. Besides, the fusion point of aluminum is 660.4℃, so the panel is ultimately fireproof.  Since it weighs much lighter but with high intensity, the panel can be widely used on curtain wall. Especially on buildings, it’s capable to bear strong wind pressure so that it meets requirement for large lattices on the curtain wall of super big & high buildings. This product also has good flatness and it is easy to process.
Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas 4
Environmentally Friendly PVDF Painting Aluminum Honeycomb Panel for Exterior Areas 5
